The '''Button''' component is an interactive [[UIX]] element that allows for users to click on its [[Component:RectTransform|RectTransform]]. It can provide visual feedback by altering the colors of graphics on the RectTransform [[Slot]], such as the [[Component:Image|Image]] component. This is able to trigger several other components, such as [[Component:TextField|Text Field]], by using the [[Button Events]] system.
A Button is a [[UIX]] component allows for users to click on its Rect. It provides visual feedback by altering the colors of graphics on the Rect, and is able to trigger several other components, such as [[Text Field (Component)|Text Field]], by using the [[Button Events]] system.
<!--T:3-->
<!--T:3-->
== Usage ==
{{Table ComponentFields
{{Table ComponentFields
|BaseColor|ColorX|The color that all other tints will be based on
|BaseColor|ColorX|The color that all other tints will be based on
|ColorDrivers|{{RootFieldType|SyncList`1|[[Type:ColorDriver|ColorDriver]]}}|TypeAdv1=true|A list of sets of colors. Each one points at another component's color, and determines how it looks normally, when highlighted, when pressed, and when disabled
|ColorDrivers|{{RootFieldType|SyncList`1|[[Type:ColorDriver|ColorDriver]]}}|TypeAdv1=true|A list of sets of colors. Each one points at another component's color, and determines how it looks normally, when highlighted, when pressed, and when disabled
|__legacy_NormalColor|ColorX|
|__legacy_NormalColor|ColorX|Legacy normal button color.
|__legacy_ColorDrive|{{RootFieldType|FieldDrive`1|[[Type:ColorX|ColorX]]}}|TypeAdv7=true|Legacy color drive button.
|IsPressed|Bool|True if the button is being pressed
|IsPressed|Bool|True if the button is being pressed
|IsHovering|Bool|True if someone is hovering over the button
|IsHovering|Bool|True if someone is hovering over the button
|HoverVibrate|VibratePreset|How a controller should vibrate when hovering over this button
|HoverVibrate|VibratePreset|How a controller should vibrate when hovering over this button
|PressVibrate|VibratePreset|How a controller should vibrate when pressing this button
|PressVibrate|VibratePreset|How a controller should vibrate when pressing this button
|ClearFocusOnPress|Bool|If set, will defocus any currently focused [[TextEditor]], [[DesktopInteractionRelay]], or any other [[IFocusable]] when this button is pressed. Defaults to true.
|ClearFocusOnPress|Bool|If set, will defocus any currently focused [[Component:TextEditor|TextEditor]], [[DesktopInteractionRelay]], or any other [[IFocusable]] when this button is pressed. Defaults to true.
|PassThroughHorizontalMovement|Bool|Whether or not press-and-drag movement should be passed to higher components
|PassThroughHorizontalMovement|Bool|Whether or not press-and-drag movement should be passed to higher components
(such as [[Scroll Rect (Component)|Scroll Rect]]s)
(such as [[Scroll Rect (Component)|Scroll Rect]]s)
|PassThroughVerticalMovement|Bool|Whether or not press-and-drag movement should be passed to higher components
|PassThroughVerticalMovement|Bool|Whether or not press-and-drag movement should be passed to higher components
(such as [[Scroll Rect (Component)|Scroll Rect]]s)
(such as [[Scroll Rect (Component)|Scroll Rect]]s)
|RequireLockInToPress|Bool|FIXME. Defaults to false.
|RequireLockInToPress|Bool|Internal. Defaults to false.
|RequireInitialPress|Bool|FIXME. Defaults to true.
|RequireInitialPress|Bool|Internal - Check for the initial press of the button. Defaults to true.
|PressPoint|Float2|The (x,y) coordinate where the button is being pressed
|PressPoint|Float2|The (x,y) coordinate where the button is being pressed
|SendSlotEvents|Bool|If set, all Pressing, Pressed, Released, HoverEnter, HoverStay, and HoverLeave events are sent to all [[IButtonPressReceiver]] components within this component's slot. Defaults to true.
|SendSlotEvents|Bool|If set, all Pressing, Pressed, Released, HoverEnter, HoverStay, and HoverLeave events are sent to all [[IButtonPressReceiver]] components within this component's slot. Defaults to true.
Line 45:
Line 41:
}}
}}
== Behavior ==
== Usage ==
This can be used with [[ProtoFlux]], and specifically the [[ProtoFlux:Button Events|Button Events]] node. Allowing it to fire [[Impulses]] from this [[Type:IButton|IButton]] reference.
<!--T:5-->
<!--T:5-->
== Examples ==
== Examples ==
[[File:UIX Button Example 01.png|alt=A button from the Resonite Essentials folder.|thumb|A button from the Resonite Essentials folder.]]
There is a button UI Preset from the [[Resonite Essentials]] folder that users can use as a starting point for buttons.
Here is [[User:ProbablePrime|ProbablePrime]]'s tutorial on Buttons:
The Button component is an interactive UIX element that allows for users to click on its RectTransform. It can provide visual feedback by altering the colors of graphics on the RectTransform Slot, such as the Image component. This is able to trigger several other components, such as Text Field, by using the Button Events system.
A list of sets of colors. Each one points at another component's color, and determines how it looks normally, when highlighted, when pressed, and when disabled
If set, all Pressing, Pressed, Released, HoverEnter, HoverStay, and HoverLeave events are sent to all IButtonPressReceiver components within this component's slot. Defaults to true.
